APM Power Module V1.0 with XT60 Plug for Pixhawk Flight Controller

Description

APM Power Module V1.0 with XT60 Plug for Pixhawk Flight Controller

This APM Power Module V1.0 is a simple way of providing your APM/Arduflyer with clean power from a LiPo battery as well as current consumption and battery voltage measurements, all through a 6P cable. The on-board switching regulator outputs 5.3V and a maximum of 3A from up to a 7S LiPo battery. Special for APM2.5.2 APM2.6

A six wire cable from the Power Module is plugged into your Pixhawk/APM power port. This enables current consumption and battery voltage measurement data to you Flight Controller via the DF13 plug. The six wire cable is approximately 7-inches long. The battery cable is 12AWG extending approximately 6-inches between the male and female XT60 connectors.

Note: The Power Module is only designed to power APM, a RC receiver and APM accessories (GPS, 3DR radio). It is not designed to power servos.

Specifications:

• Max input voltage: 18V
• Max current sensing: 90A
• Voltage and current measurement configured for 5V ADC
• Switching regulator outputs 5.3V and 2.25A max
• 6-pos DF13 cable plugs directly to APM 2.5’s ‘PM’ connector

Package Includes:
1 x APM POWER MODULE WITH XT60 CONNECTOR
